Horizontal Ultramill Type Mill
The SHIKHAR™ Ultramill Type Stone Mill is an ultra heavy-duty flour mill machine engineered for high-output commercial milling plants. Designed for continuous, large-scale production, it is trusted by high-capacity millers for delivering consistent grinding performance in demanding industrial environments. Ideal for flour mill plant installations, this machine ensures efficient processing of grains, spices, pulses, henna, condiments, snuff, and other dry materials.
- Applications: Big Atta Plants, Heavy & continuous milling requirements.
- Ideal For: All dry, non oily food items & cosmetics.
- Base Plate & Shaft: 16mm & 60mm
Built using premium-grade tensile steel and first-grade iron, the Ultramill is designed to withstand rigorous daily operations and heavy loads. Its advanced construction and high-performance components allow uninterrupted operation over extended hours. Equipped with long-lasting NBC®/SKF® bearings, the machine ensures smooth functioning, reduced downtime, and reliable performance in high-volume milling setups.
Key Features of Horizontal Ultramill Type Mill:
- Ultra Heavy-Duty Channel Frame: Constructed with high-strength, first-grade iron channels for superior durability and structural stability in industrial use.
- Low-Vibration Technology: Engineered to minimize vibrations during operation, improving machine stability, reducing wear, and enhancing grinding efficiency.
- Continuous High-Output Operation: Designed for non-stop use, ensuring maximum productivity and consistent output in commercial flour milling plants.
- Premium Bearing System: Fitted with quadruple NBC®/SKF® dust-resistant bearings for smooth operation and long-term durability under intensive use.
- Superior Build Quality: Assembled using high-quality nuts, bolts, washers, studs, and components to ensure strength, reliability, and extended service life.
| Bottom Rotating Stone Diameter Size | Tapered Shaft Thickness (MM) | Upper Bearing Size | Lower Bearing Size | Angles Legs Dimensions | Pulley Drive Size Available | Suggested Machine RPM | Electrical Motor HP required (Three Phase) | Hopper Capacity (Kgs) | Net Weight (Kgs) w/o emery millstones, electric motor & accessories | Gross Weight (Kgs) with RED emery stones but w/o motor or accessories | Gross Weight (Kgs) with BLACK emery stones but w/o motor or accessories | Average output in Kgs (Medium fineness Whole Wheat Flour as per Factory test conditions) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
750 MM (30”) |
60 |
6312 |
6209 |
100MMx50MMx50MMx06MM |
14”x3C |
500 |
25 |
50 |
335 |
560 |
615 |
250 |
Kindly Note:
- Above Dimensions & Weights are approximate & indicative. Actuals may vary.
- Outputs are approximate and as per factory test condition only. Actuals may vary.
- Dimensions, Features and Weights may change without prior information.
- All weights and dimensions are without motor, generator, belt, starter, panel or any other accessories unless stated otherwise.
